Difference between hot rolling and cold rolling

    It’s important to note that the main difference between hot rolled and cold rolled steel is one of process. “Hot rolling” refers to processing done with heat. “Cold rolling” refers to processes done at or near room temperature. Although these techniques affect overall performance and application, they should not be confused with formal specifications and grades of steel, which relate to metallurgical composition and performance ratings. Steels of different grades and specifications can be either hot rolled or cold rolled—including both basic carbon steels and other alloy steels. Knowing which to use can help avoid over-spending on raw materials. It can also save time and money on additional processing. Understanding the differences between hot and cold steel is integral to choosing one over the other.

    Hot rolled steel is steel that has been roll-pressed at very high temperatures—over 1,700˚F, which is above the re-crystallization temperature for most steels. This makes the steel easier to form, and resulting in products that are easier to work with.

    To process hot rolled steel, manufacturers first start with a large, rectangular length of metal, called a billet. The billet is heated and then sent for pre-processing, where it is flattened into a large roll. From there, it is kept at a high temperature and run through a series of rollers to achieve its finished dimensions. The white-hot strands of steel are pushed through the rollers at high speeds. For sheet metal, rolled steel is spun into coils and left to cool. For other forms, such as bars or plates, materials are sectioned and packaged.

    Steel shrinks slightly as it cools. Since hot rolled steel is cooled after processing, there is less control over its final shape, making it less suitable for precision applications. Hot rolled steel is often used in applications where minutely specific dimensions aren’t crucial. Railroad tracks and construction projects often use hot rolled steel.

    Hot rolled steel can often be identified by the following characteristics:

    A scaled surface—a remnant of cooling from extreme temperatures

    Slightly rounded edges and corners for bar and plate products (due to shrinkage and less precise finishing)Slight distortions, where cooling may result in slightly trapezoidal forms, as opposed to perfectly squared angles

    Hot rolled steel typically requires much less processing than cold rolled steel, which makes it a lot cheaper. Because hot rolled steel is allowed to cool at room temperature, it’s essentially normalized—meaning it’s free from internal stresses that can arise from quenching or work-hardening processes.

    Hot rolled steel is ideal where dimensional tolerances aren’t as important as overall material strength, and where surface finish isn’t a key concern. Where surface finish is a concern, scaling can be removed by grinding, sand blasting, or acid-bath pickling.

    Cold rolled steel is essentially hot rolled steel that has been through further processing. Once hot rolled steel has cooled, it is then re-rolled at room temperature to achieve more exact dimensions and better surface qualities.

    Cold rolled steel can often be identified by the following characteristics:Better, more finished surfaces with closer tolerances

    Smooth surfaces that are often oily to the touch ，Bars are true and square, and often have well-defined edges and corners

    Tubes have better concentric uniformity and straightness.

    With better surface characteristics than hot rolled steel, it’s no surprise that cold rolled steel is often used for more technically precise applications, or where aesthetics are important. But due to the additional processing for cold finished products, they come at a higher price.

    In terms of physical characteristics, cold rolled steels are typically harder and stronger than standard hot rolled steels. As the metal is shaped at the lower temperatures, the steel’s hardness, resistance against tension breaking, and resistance against deformation are all increased due to work hardening.

    These additional treatments, however, can also create internal stress within the material. This can cause unpredictable warping if the steel is not stress relieved prior to cutting, grinding, or welding.

    It’s important to note that the main difference between hot rolled and cold rolled steel is one of process. “Hot rolling” refers to processing done with heat. “Cold rolling” refers to processes done at or near room temperature. Although these techniques affect overall performance and application, they should not be confused with formal specifications and grades of steel, which relate to metallurgical composition and performance ratings. Steels of different grades and specifications can be either hot rolled or cold rolled—including both basic carbon steels and other alloy steels. Knowing which to use can help avoid over-spending on raw materials. It can also save time and money on additional processing. Understanding the differences between hot and cold steel is integral to choosing one over the other.

    Hot rolled steel is steel that has been roll-pressed at very high temperatures—over 1,700˚F, which is above the re-crystallization temperature for most steels. This makes the steel easier to form, and resulting in products that are easier to work with.

    To process hot rolled steel, manufacturers first start with a large, rectangular length of metal, called a billet. The billet is heated and then sent for pre-processing, where it is flattened into a large roll. From there, it is kept at a high temperature and run through a series of rollers to achieve its finished dimensions. The white-hot strands of steel are pushed through the rollers at high speeds. For sheet metal, rolled steel is spun into coils and left to cool. For other forms, such as bars or plates, materials are sectioned and packaged.

    Steel shrinks slightly as it cools. Since hot rolled steel is cooled after processing, there is less control over its final shape, making it less suitable for precision applications. Hot rolled steel is often used in applications where minutely specific dimensions aren’t crucial. Railroad tracks and construction projects often use hot rolled steel.

    Hot rolled steel can often be identified by the following characteristics:

    A scaled surface—a remnant of cooling from extreme temperatures

    Slightly rounded edges and corners for bar and plate products (due to shrinkage and less precise finishing)Slight distortions, where cooling may result in slightly trapezoidal forms, as opposed to perfectly squared angles

    Hot rolled steel typically requires much less processing than cold rolled steel, which makes it a lot cheaper. Because hot rolled steel is allowed to cool at room temperature, it’s essentially normalized—meaning it’s free from internal stresses that can arise from quenching or work-hardening processes.

    Hot rolled steel is ideal where dimensional tolerances aren’t as important as overall material strength, and where surface finish isn’t a key concern. Where surface finish is a concern, scaling can be removed by grinding, sand blasting, or acid-bath pickling.

    Cold rolled steel is essentially hot rolled steel that has been through further processing. Once hot rolled steel has cooled, it is then re-rolled at room temperature to achieve more exact dimensions and better surface qualities.

    Cold rolled steel can often be identified by the following characteristics:Better, more finished surfaces with closer tolerances

    Smooth surfaces that are often oily to the touch ，Bars are true and square, and often have well-defined edges and corners

    Tubes have better concentric uniformity and straightness.

    With better surface characteristics than hot rolled steel, it’s no surprise that cold rolled steel is often used for more technically precise applications, or where aesthetics are important. But due to the additional processing for cold finished products, they come at a higher price.

    In terms of physical characteristics, cold rolled steels are typically harder and stronger than standard hot rolled steels. As the metal is shaped at the lower temperatures, the steel’s hardness, resistance against tension breaking, and resistance against deformation are all increased due to work hardening.

    These additional treatments, however, can also create internal stress within the material. This can cause unpredictable warping if the steel is not stress relieved prior to cutting, grinding, or welding.
